Apv Phe Gasket And Plates
Apv Phe Gasket And Plates
SRJ HEATT EXCHANGERS INDIA PVT LTD. is a Replacement Manufacturer of Plate Heat Exchanger (Phe) Gaskets, Plate and Frame Heat Exchangers or for Plates for Plate and Frame Heat Exchangers. We also engineer, thermal rate, expand, clean, and sell plate and frame heat exchangers. We have been stocking and selling plate heat exchanger gaskets and heat exchangers for nearly 15 years.
All sizes shown below are in millimeters for use on the chart to the right. Contact us for any aspect related to gaskets or plate and frame heat exchangers, as well as modifications or new equipment.
| Model | |||
| APV FFPE | APV MK, III | APV MK, II | APV Super Junior PE |
| APV Junior | APV SR1 | APV SR1 Clip | APV HX |
| APV HMB | APV SR2 Clip | APV SR3 | APV SR3 Clip |
| APV SR6AA Clip | APV SR6AG Clip | APV SR6GL Clip | APV SR6GH Clip |
| APV R5 Clip | APV R5 | APV R4-R405 | APV R8GI |
| APV A085 | APV TR9AV | APV B063 | |
APV Technical Parameters
| Model | Corrugation Angle | Corrugation Depth (mm) | Angle Hole Diameter (mm) |
|---|---|---|---|
| T4 | Horizontal 120° | 2.5 | φ32 |
| FH12 | Horizontal/ Vertical 120° | 3 | φ74 |
| H12Water Generator | 120° | 3 | φ74 |
| FH17 | Horizontal/ Vertical 120° | 3 | φ74 |
| FN35 | Horizontal/ Vertical 120° | 2.8 | φ85 |
| FN25 | Horizontal 120° | 2.8 | φ85 |
| FN50 | Horizontal 120° | 2.8 | φ85 |
| Q030E | 60°120° | 3 | φ114 |
| Q030Deep | 121° 61° | 4.2 | φ112 |
| Q055E | 120°60° | 3 | φ114 |
| Q055Deep | 121° 61° | 4.2 | φ112 |
| Q080Deep | 121° 61° | 4.2 | φ112 |
| Q080E | 120° | 3 | φ114 |
| A055 | 50°120° | 3.2 | φ150 |
| A085 | 50°120° | 3.2 | φ150 |
| A145 | 120° | 3.2 | φ150 |
| J060 | 60°120° | 3 | φ229 |
| J092 | 60°120° | 3 | φ229 |
| J107 | 60°120° | 3 | φ229 |
| J185 | 120° | 3 | φ229 |
| M107 | Vertical 121° / Horizontal 121° | 2.8 | φ229 |
| M092 | Vertical 121° / Horizontal 121° | 2.8 | φ229 |
| M060 | Vertical 121°/ Horizontal 121° | 2.8 | φ229 |
| R14 | 90° 180° | 3.3 | φ252.7 |
| R10 | 180° | 5.4 9.6 | φ197 |
| SR9 | 50° 180° | 5.3 | φ200 |
| R8GI | 76° 180° | 3.6 | φ148 |
| SR6GL | 80° 180° | 3.8 | φ102 |
| SR6AG | 80° 180° | 3.8 | φ102 |
| R5 | 120° | 5.4 | φ101.4 |
| SR3 | 80° 180° | 3.65 | φ73.9 |
| SR2 | 46° 180° 90° | 2.6 | φ63.5 |
| B205 | 60° 123° | 3.2 | φ300 |
| B158 | 60° 123° | 3.2 | φ300 |
| B134 | 60° 123° | 3.2 | φ300 |
| B110 | 60° 123° | 3.2 | φ300 |
| B063 | 60° 123° | 3.2 | φ300 |
| P190 | Vertical 120° | 4.6 | φ336 |
| P105 | Vertical 120° | 4.6 | φ336 |
| TR9AL | 90° 180° | 3 | φ200 |
| TR9AV | 90° 180° | 3 | φ200 |
| TR9GN | 90° 180° | 3 | φ200 |
| TR9GL | 90° 180° | 3 | φ200 |
| K71 | 122° | 4 | φ115 |
| K55 | 122° | 4 | φ115 |
| K34 | 122° | 4 | φ115 |
